Autel MaxiCharger vs Tesla Wall Connector

The most output a home circuit will usually carry, against Tesla's own unit. Close on speed; far apart on connector and on how you can install them.

By Sawyer V. · Published September 10, 2026

A blue Tesla sedan plugged in to charge outside a building
Illustrative photo.

How this page is funded: we earn a commission if you buy through our Amazon links, at no extra cost to you. It does not change what we recommend, and we say plainly when the honest answer is to buy nothing. Full disclosure.

At the top of the home-charging range, 50 A and 48 A are nearly the same thing -- both need a 60 A-plus circuit and a car that can take 11 kW or more. What actually separates these two is the plug on the end and whether you want the option of a receptacle.

Side by side

Published specifications
Autel MaxiCharger AC HomeTesla Wall Connector (Gen 3)
Maximum output50 A / 12 kW hardwired; 40 A plug-in48 A / 11.5 kW
ConnectorSAE J1772NACS (Tesla)
Cable25 ft24 ft
InstallationHardwired, or NEMA 14-50 / 6-50 plugHardwired
EnclosureNEMA Type 4Rated for indoor and outdoor use
CertificationTested to UL standards by CSAListed to applicable UL standards
Warranty3 years4 years
From each manufacturer's published documentation, listed at the foot of this page.

The circuit each one needs

The continuous-load rule

Autel at 50 A hardwired: 50 x 1.25 = 62.5, so a 70 A circuit

Tesla at 48 A: 48 x 1.25 = 60 A circuit

Autel at 40 A plug-in: 50 A circuit and a 14-50 or 6-50 receptacle

The installation manual states the circuit, and governs

Who should buy which

  • Every car a Tesla: the Wall Connector, for the connector and the extra warranty year.
  • A J1772 car, or a mixed garage: the Autel, which serves both through the Tesla's adapter.
  • You want to plug in, or might move house: the Autel's 14-50 or 6-50 versions. Hardwired vs plug-in.

The two, at a glance

Ranked for a first home charger. Every row jumps to the full write-up below.

#ProductBest forMax outputPrice
1Autel MaxiCharger AC HomeLong reach outdoors. J1772, 25 ft cable.Long reach outdoors50 A12 kWCheck price on Amazon#ad how we are funded
2Tesla Wall Connector (Gen 3)Tesla owners. NACS, 24 ft cable.Tesla owners48 A11.5 kWCheck price on Amazon#ad how we are funded

Both chargers in full

Full specifications and the case against each.

1. Long reach outdoors

Autel MaxiCharger AC Home

Autel Energy · J1772 · 50 A / 12 kW · 25 ft cable

The 25 ft cable is the longest in this group, and the NEMA 4 case plus a cold-flexible cord make it the easiest unit to live with on an exposed outside wall.

What is good

  • 25 ft cable, the longest of the wall units here
  • Sold in NEMA 14-50, NEMA 6-50 and hardwired versions
  • NEMA Type 4 enclosure rated for rain, snow, hail and sleet
  • Wi-Fi and Bluetooth, so it still works if the Wi-Fi drops

What is not

  • The 50 A version is hardwired only
  • The app has more features than a first-time owner needs
Published specifications for the Autel MaxiCharger AC Home
Maximum output50 A / 12 kW hardwired; 40 A / 9.6 kW plug-in
ConnectorSAE J1772
Cable25 ft
EnclosureNEMA Type 4
CertificationTested to UL standards by CSA
Warranty3 years

Skip this if: Skip it if your parking spot is right next to the panel. You are paying for cable you will coil up and never use.

Specifications above are the manufacturer’s published figures. Source: Autel Energy. We have not tested this unit — see how we pick.

Check price on Amazon#ad how we are funded

2. Tesla owners

Tesla Wall Connector (Gen 3)

Tesla · NACS · 48 A / 11.5 kW · 24 ft cable

48 A, a 24 ft cable and a four-year warranty, the longest in this group. The catch is the connector: Gen 3 is NACS, so a J1772 car needs an adapter.

What is good

  • Four-year warranty, longer than the three-year standard here
  • Up to six units can share one circuit for a two-EV household
  • Wi-Fi with over-the-air firmware updates
  • Scheduled departure and charge stats live in the Tesla app

What is not

  • NACS connector, so a J1772 car needs an adapter on every charge
  • Hardwired only
Published specifications for the Tesla Wall Connector (Gen 3)
Maximum output48 A / 11.5 kW at 240 V
ConnectorNACS (Tesla)
Cable24 ft
InstallationHardwired
Power sharingUp to six units can be linked
Warranty4 years

Skip this if: Skip it if you drive a J1772 car and do not want to keep an adapter on the cable. Buy a J1772 unit instead.

Specifications above are the manufacturer’s published figures. Source: Tesla, Tesla. We have not tested this unit — see how we pick.

Check price on Amazon#ad how we are funded

The verdict

Tesla Wall Connector for a Tesla-only household. Autel MaxiCharger for J1772 cars, a mixed garage, or anyone who wants a plug-in option. For both connectors on one Tesla-built unit, see the Universal Wall Connector.

FAQ

Questions people actually ask

Is Autel or the Tesla Wall Connector better?
For a Tesla-only household, the Wall Connector: NACS, 48 A and a four-year warranty. For J1772 cars, a mixed household, or a plug-in install, the Autel MaxiCharger, which reaches 50 A hardwired.
Can a Tesla use an Autel MaxiCharger?
Yes, through the J1772 adapter that comes with a Tesla.
Which is faster, Autel or Tesla?
On paper the Autel, at 50 A hardwired against 48 A -- but only if your car's onboard charger accepts about 12 kW and your panel can carry a 70 A circuit.

Sources

Where these numbers come from

  1. MaxiCharger AC Home specifications — Autel Energy
  2. Wall Connector Gen 3 installation manual — Tesla
  3. Wall Connector support page — Tesla
