Lectron NEXUS vs Wallbox Pulsar Plus

How this page is funded: we earn a commission if you buy through our Amazon links, at no extra cost to you. It does not change what we recommend, and we say plainly when the honest answer is to buy nothing. Full disclosure.

These two rarely appear on the same shortlist, which is a shame, because they are the clearest illustration of the one real choice in this class: a charger you configure from your phone, or a charger that has nothing to configure.

Side by side

The app question, made concrete

The Pulsar Plus is configured in its app, including the current setting -- which is genuinely useful if your circuit changes, or if you want to dial the charger back while something else runs. It also means setup depends on a phone, an account and a Wi-Fi signal at the far end of the house.

The NEXUS has none of that. Its current is set at installation and then it behaves like an appliance. Scheduling happens in the car, which every EV can do. Charging at night covers that route, and the no-app roundup covers the category.

Installation flexibility

This is the NEXUS's quiet advantage: Lectron sells a 40 A plug-in version of the same charger. If your panel will not stretch to a 60 A circuit, you can still buy the unit and put it on an existing NEMA 14-50. The 48 A Pulsar Plus has no plug-in equivalent. Hardwired vs plug-in.

Which one to buy

• Buy the NEXUS if you want no software, a NACS option, or the flexibility to run it at 40 A on a plug.
• Buy the Pulsar Plus if wall space is tight, or if you want to change the charging current from your phone rather than call an electrician.
• Buy neither if your panel cannot carry 60 A -- the 40-amp tier is the sensible fallback.

The two chargers

Same output, same circuit. One has an app; the other deliberately does not.

1. A long cable, no app

L48A

Lectron NEXUS Level 2 charger

Lectron · J1772 · 48 A / 11.5 kW · 23 ft cable

Lectron's wall charger: 48 A hardwired or 40 A on a NEMA 14-50, with a 23 ft cable, an IP66 housing and ETL listing to UL 2594, UL 2231 and UL 2251. Sold with a J1772 or NACS connector -- and with no app at all.

What is good

• +23 ft of cable, among the longest on this site
• +48 A hardwired, or 40 A from an existing NEMA 14-50
• +ETL listed to UL 2594, UL 2231 and UL 2251 -- a listing, not a claim of compliance
• +Wall mount, J-hook and plug holder included

What is not

• −No app, Wi-Fi or scheduling on Lectron's NEXUS pages
• −The 48 A version is hardwired only, so it needs an electrician and a 60 A circuit
• −Lectron does not publish an operating temperature range for it

Published specifications for the Lectron NEXUS Level 2 charger

Maximum output	48 A / 240 V / 11.5 kW, hardwired
Plug-in version	40 A / 240 V / 9.6 kW on a NEMA 14-50
Connector	SAE J1772, or NACS (SAE J3400), chosen at purchase
Cable	23 ft
Cable thickness	15.0 mm (J1772) or 16.0 mm (NACS), per Lectron
Enclosure	IP66 automotive-grade housing; UL 94 V-0 flame-retardant, per the NACS page
Protections	Overheating, overcurrent, voltage faults and ground faults
In the box	Wall mount, J-hook and plug holder
Certification	UL 2594, UL 2231, UL 2251 (ETL listed); Energy Star; FCC
Warranty	3 years

Skip this if: Skip it if you want scheduling or energy tracking on your phone. Lectron's NEXUS pages list no app, Wi-Fi or Bluetooth.

Specifications above are the manufacturer’s published figures. Source: Lectron, Lectron, Lectron. We have not tested this unit — see how we pick.

Check price on Amazon#ad how we are funded

2. Tight wall space

Wallbox Pulsar Plus

Wallbox · J1772 · 48 A / 11.5 kW · 25 ft cable

The smallest 48 A unit here at roughly 7.8 by 7.9 inches, which matters more than it sounds when the only free wall is beside a door.

What is good

• +Smallest body of the 48 A units, under 8 inches square
• +Current configurable in steps from 6 A to 48 A
• +NEMA Type 4 enclosure, rated down to -22 F
• +Weighs 4.4 lb without the cable, so mounting is simple

What is not

• −Hardwired only at 48 A, with no plug-in version at full output
• −Setup runs through the app, which some owners find fussy

Published specifications for the Wallbox Pulsar Plus

Maximum output	48 A / 11.5 kW at 240 V
Configurable current	6 A to 48 A
Connector	SAE J1772
Cable	25 ft
Body size	7.8 x 7.9 x 3.9 inches without the cable
Operating temperature	-22 F to 104 F
Certification	UL 2594, UL 2231
Warranty	3 years

Skip this if: Skip it if you want a plug-in unit you can take with you. The 48 A Pulsar Plus is hardwired.

Specifications above are the manufacturer’s published figures. Source: Wallbox, Wallbox. We have not tested this unit — see how we pick.

$699.99 · View on Amazon#ad how we are funded · price as of September 27, 2026
