Leviton EV480 vs Wallbox Pulsar Plus

How this page is funded: we earn a commission if you buy through our Amazon links, at no extra cost to you. It does not change what we recommend, and we say plainly when the honest answer is to buy nothing. Full disclosure.

Neither of these is a plug-in charger, so both assume an electrician and a 60-amp circuit. Once that is settled, they solve different problems: the Pulsar Plus is the small one with the long cable, and the EV480 is the one that can be locked to an authorized user.

Side by side

Cable: 25 feet against 18

Seven feet is the biggest practical gap between these two. An 18 ft cord is fine when the charge port parks within a few feet of the wall, and frustrating when it does not -- and you cannot extend it later. Cable length walks the measurement, and the answer is nearly always longer than people guess.

Heat and cold

Both are rated to -22 F, so cold is a tie. Heat is not: Leviton publishes 122 F against Wallbox's 104 F. In a closed garage in a hot climate, that headroom is worth having -- chargers for hot weather covers why chargers derate when they get hot.

Access control, and who needs it

The EV480 offers RFID access control, shipped disabled. It is a real answer for a charger on an open driveway, in a shared parking area or at a small business, where an app-based lock is clumsy. For a charger inside a private garage it is a feature you will never enable. Chargers with access control covers the category.

Which one to buy

• Buy the Pulsar Plus if wall space is tight or your parking spot is far from the wall. It is the smallest 48 A unit here and carries the longer cable.
• Buy the EV480 if you need RFID access control, your garage gets hot, or you want the longest published list of UL standards plus ENERGY STAR certification.
• Buy neither if you cannot support a 60 A circuit. The 40-amp tier is the sensible fallback.

The two units

Same 48 amps, same 60 A circuit. Cable, heat rating and access control decide it.

1. Tight wall space

Wallbox Pulsar Plus

Wallbox · J1772 · 48 A / 11.5 kW · 25 ft cable

The smallest 48 A unit here at roughly 7.8 by 7.9 inches, which matters more than it sounds when the only free wall is beside a door.

What is good

• +Smallest body of the 48 A units, under 8 inches square
• +Current configurable in steps from 6 A to 48 A
• +NEMA Type 4 enclosure, rated down to -22 F
• +Weighs 4.4 lb without the cable, so mounting is simple

What is not

• −Hardwired only at 48 A, with no plug-in version at full output
• −Setup runs through the app, which some owners find fussy

Published specifications for the Wallbox Pulsar Plus

Maximum output	48 A / 11.5 kW at 240 V
Configurable current	6 A to 48 A
Connector	SAE J1772
Cable	25 ft
Body size	7.8 x 7.9 x 3.9 inches without the cable
Operating temperature	-22 F to 104 F
Certification	UL 2594, UL 2231
Warranty	3 years

Skip this if: Skip it if you want a plug-in unit you can take with you. The 48 A Pulsar Plus is hardwired.

Specifications above are the manufacturer’s published figures. Source: Wallbox, Wallbox. We have not tested this unit — see how we pick.

$699.00 · View on Amazon#ad how we are funded · price as of September 24, 2026

2. RFID access control

Leviton EV Series 48 A charger (EV480)

Leviton · J1772 · 48 A / 11.5 kW · 18 ft cable

Leviton's hardwired 48-amp EV Series unit: an 18 ft J1772 cord, a NEMA Type 3R enclosure rated -22 F to 122 F, optional RFID access control and ENERGY STAR certification. The EV48W version adds Wi-Fi and the My Leviton app.

What is good

• +Optional RFID access control for a shared or open driveway
• +NEMA Type 3R enclosure rated -22 F to 122 F
• +ENERGY STAR certified, with a long list of published UL standards
• +Pre-attached input cable and mounting hardware included

What is not

• −18 ft cord, shorter than most 48 A units on this site
• −Hardwired only
• −The app is on the Wi-Fi EV48W, not the EV480

Published specifications for the Leviton EV Series 48 A charger (EV480)

Output	48 A, 208/240 V; Leviton quotes 11.6 kW
Breaker	60 A
Connector	SAE J1772
Cord	18 ft
Enclosure	NEMA Type 3R
Operating temperature	-22 F to 122 F
Access control	Optional RFID, disabled when shipped
Status lights	Power present, charging, fault
Standards	UL 2594, UL 2231-1, UL 2231-2, UL 2251, among others
Wi-Fi version	EV48W, with the My Leviton app

Skip this if: Skip it if your charge port is far from the wall -- the cord is 18 ft -- or if you want a plug-in unit. The EV480 is hardwired only.

Specifications above are the manufacturer’s published figures. Source: Leviton, Leviton. We have not tested this unit — see how we pick.

$706.43 · View on Amazon#ad how we are funded · price as of September 24, 2026
